Heap corruption, module variety, execution residue, coincidental symbolic information and critical section corruption: pattern cooperation

This is a synthesized dump analysis of many similar print spooler crashes in multi-user terminal service environments where old printer drivers are used that were tested only in single-user environments or insufficiently tested in multi-threaded environments. Many such crashes result from dynamic memory corruption of a process heap:

(40dc.4278): Access violation - code c0000005 (!!! second chance !!!)
eax=00000079 ebx=00000001 ecx=0008bff8 edx=00107898 esi=07d7522a edi=00107890
eip=7c8199b2 esp=0155fc14 ebp=0155fc44 iopl=0 nv up ei pl nz na po nc
cs=001b ss=0023 ds=0023 es=0023 fs=003b gs=0000 efl=00010202
ntdll!RtlpLowFragHeapFree+0×30:
7c8199b2 8b4604          mov     eax,dword ptr [esi+4] ds:0023:07d7522e=????????

0:017> kL
ChildEBP RetAddr
0155fc44 7c819770 ntdll!RtlpLowFragHeapFree+0×30
0155fd1c 77c87a2b ntdll!RtlFreeHeap+0×5c

0155fd30 77c87a02 RPCRT4!FreeWrapper+0×1e
0155fd3c 77c821c2 RPCRT4!operator delete+0xd
0155fd50 77c8047b RPCRT4!LRPC_SCALL::FreeBuffer+0×77
0155fd9c 77c80353 RPCRT4!RPC_INTERFACE::DispatchToStubWorker+0×192
0155fdc0 77c811dc RPCRT4!RPC_INTERFACE::DispatchToStub+0xa3
0155fdfc 77c812f0 RPCRT4!LRPC_SCALL::DealWithRequestMessage+0×42c
0155fe20 77c88678 RPCRT4!LRPC_ADDRESS::DealWithLRPCRequest+0×127
0155ff84 77c88792 RPCRT4!LRPC_ADDRESS::ReceiveLotsaCalls+0×430
0155ff8c 77c8872d RPCRT4!RecvLotsaCallsWrapper+0xd
0155ffac 77c7b110 RPCRT4!BaseCachedThreadRoutine+0×9d
0155ffb8 77e64829 RPCRT4!ThreadStartRoutine+0×1b
0155ffec 00000000 kernel32!BaseThreadStart+0×34

Although any module could corrupt the heap and either Gflags or Application Verifier is recommended to enable full page heap, sometimes we need to point to some print drivers to eliminate or upgrade them in the meantime. When there are many of them we can point to the oldest one:

0:017> lmt
start    end        module name
[...]
010d0000 010d8000   PrintDriver1  2007
01260000 01272000   PrintDriver2  1999
01290000 012da000   PrintDriver3  2009
012f0000 01302000   PrintDriver4  2003
01310000 01320000   PrintDriver5  2004
01320000 01332000   PrintDriver6  2004
01340000 01353000   PrintDriver7  2005
01360000 0139e000   PrintDriver8  2007
013b0000 013c3000   PrintDriver9  2004
013d0000 013e0000   PrintDriver10 2005
013e0000 013f3000   PrintDriver11 2005
01400000 01413000   PrintDriver12 2006
01420000 0146b000   PrintDriver13 2007
01480000 01488000   PrintDriver14 2003
017f0000 0181e000   PrintDriver15 2004
01920000 0192d000   PrintDriver16 2008
01930000 01936000   PrintDriver17 2008
01950000 01959000   PrintDriver18 2008
01960000 01969000   PrintDriver19 2008
01f80000 021e8000   PrintDriver20 2004
032f0000 03514000   PrintDriver21 2003
03cd0000 03cd6000   PrintDriver22 2008
32100000 32148000   PrintDriver23 2008
3ea40000 3ea46000   PrintDriver24 2007
3f000000 3f03d000   PrintDriver25 2009
3f100000 3f133000   PrintDriver26 2009
[…]

The age distribution among 121 modules can be visualized on a CAD diagram:



Alternatively we can look at the execution residue on a raw thread stack:

0:017> !teb
TEB at 7ffa9000
    ExceptionList:        0155fd0c
    StackBase:            01560000
    StackLimit:           01550000
    SubSystemTib:         00000000
    FiberData:            00001e00
    ArbitraryUserPointer: 00000000
    Self:                 7ffa9000
    EnvironmentPointer:   00000000
    ClientId:             000040dc . 00004278
    RpcHandle:            00000000
    Tls Storage:          00000000
    PEB Address:          7ffd8000
    LastErrorValue:       0
    LastStatusValue:      8000001a
    Count Owned Locks:    0
    HardErrorMode:        0

0:017> dds 01550000 01560000
01550000  00000000
01550004  00000000
[...]
01554e78  00000000
01554e7c  00000000
01554e80  01554ecc
01554e84  7c82d1bb ntdll!RtlFindActivationContextSectionString+0xe1
01554e88  01554ea4
01554e8c  01554efc
01554e90  00000000
01554e94  020a0018 PrintDriver20!Callback+0×5c88
01554e98  7ffa9c00
01554e9c  00000000
01554ea0  01554ed4
01554ea4  7c82dd6c ntdll!RtlEncodeSystemPointer+0×45b
01554ea8  00020000
01554eac  01554ec8
01554eb0  01554ec8
01554eb4  01554ec8
[…]
01555eb4  0040003e
01555eb8  01556854
01555ebc  00000000
01555ec0  0000003e
01555ec4  0208003e PrintDriver20!GetValue+0xb37fe
01555ec8  00000000
01555ecc  43000000
01555ed0  0000003e
01555ed4  01555ffa
01555ed8  01555fbc
01555edc  01555fa8
01555ee0  001190d8
01555ee4  7c81990d ntdll!RtlpLowFragHeapAlloc+0×210
01555ee8  7c819962 ntdll!RtlpLowFragHeapAlloc+0xc6a
01555eec  0008bff8
01555ef0  00000000
01555ef4  00080000
[…]

The first address 020a0018 seems to be coincidental because its disassembled code is not good:

0:017> ub 020a0018
                 ^ Unable to find valid previous instruction for 'ub 020a0018'

0:017> u 020a0018
PrintDriver20!Callback+0x5c88:
020a0018 048b            add     al,8Bh
020a001a c7              ???

020a001b ebe8            jmp     PrintDriver20!Callback+0×5c75 (020a0005)
020a001d 8d4e28          lea     ecx,[esi+28h]
020a0020 e8d9960100      call    PrintDriver20!DlgProc+0×86ee (020b96fe)
020a0025 8d4e28          lea     ecx,[esi+28h]
020a0028 e87b930100      call    PrintDriver20!DlgProc+0×8398 (020b93a8)
020a002d 8b4618          mov     eax,dword ptr [esi+18h]

However the second address code 0208003e seems sound: cmp is followed by jne:

0:017> ub 0208003e
PrintDriver20!GetValue+0xb37e5:
02080025 8d442414        lea     eax,[esp+14h]
02080029 8b4b2c          mov     ecx,dword ptr [ebx+2Ch]
0208002c 50              push    eax
0208002d e8ce3a0000      call    PrintDriver20!GetValue+0xb72c0 (02083b00)
02080032 8b38            mov     edi,dword ptr [eax]
02080034 8b4c2410        mov     ecx,dword ptr [esp+10h]
02080038 8b41fc          mov     eax,dword ptr [ecx-4]
0208003b 3947fc          cmp     dword ptr [edi-4],eax

0:017> u 0208003e
PrintDriver20!GetValue+0xb37fe:
0208003e 751b            jne     PrintDriver20!GetValue+0xb381b (0208005b)
02080040 8bc8            mov     ecx,eax
02080042 8b742410        mov     esi,dword ptr [esp+10h]
02080046 c1e902          shr     ecx,2
02080049 f3a7            repe cmps dword ptr [esi],dword ptr es:[edi]
0208004b 750e            jne     PrintDriver20!GetValue+0xb381b (0208005b)
0208004d 8bc8            mov     ecx,eax
0208004f 83e103          and     ecx,3

But this is not a function call resulted in saved return address so we can still consider it as a coincidence. However, on the raw stack we also see a large chunk of ASCII data pointing to the same driver in a textual form:

[...]
0155d360  6f742064
0155d364  696e6920
0155d368  6c616974
0155d36c  20657a69
0155d370  61636562
0155d374  20657375
0155d378  75732061
0155d37c  62617469
[...]

0:017> da 0155d360 0155d734
0155d360  "d to initialize because a suitab"
0155d380  "le PrinterDriver20 inf file was ”
[…]

This reinforces our belief in PrinterDriver20. Finally, when looking at critical section list we see corruption signs pointing to the same driver addresses:

0:017> !cs -l -o -s
DebugInfo          = 0x0014bc60
Critical section   = 0x020f7140 (PrintDriver20!DlgProc+0×46130)
LOCKED
LockCount          = 0xFF85EA7F
WaiterWoken        = Yes
OwningThread       = 0×8b0c244c
RecursionCount     = 0×8BFFFBB4
LockSemaphore      = 0×83182444
SpinCount          = 0×088908c4

WARNING: critical section DebugInfo = 0x00000008 doesn't point back
to the DebugInfo found in the active critical sections list = 0x0014bc60.
The critical section was probably reused without calling DeleteCriticalSection.

Cannot read structure field value at 0x0000000a, error 0
ntdll!RtlpStackTraceDataBase is NULL. Probably the stack traces are not enabled.
ntdll!RtlpStackTraceDataBase is NULL. Probably the stack traces are not enabled.

DebugInfo          = 0x0014bc88
Critical section   = 0x020f7110 (PrintDriver20!DlgProc+0×46100)
LOCKED
LockCount          = 0×1E7245FF
WaiterWoken        = No
OwningThread       = 0xccccc304
RecursionCount     = 0xC483FFFD
LockSemaphore      = 0×158638B9
SpinCount          = 0xff96e902

WARNING: critical section DebugInfo = 0x0f712068 doesn't point back
to the DebugInfo found in the active critical sections list = 0x0014bc88.
The critical section was probably reused without calling DeleteCriticalSection.

Cannot read structure field value at 0x0f71206a, error 0
[...]

- Dmitry Vostokov @ DumpAnalysis.org -
